Description
The Rane Major Seal Kit HFB64 is a comprehensive steering repair and overhaul solution engineered for Ashok Leyland and Tata M&HCV steering systems. Manufactured by ZF Rane Automotive India Pvt. Ltd., this kit is designed to restore complete sealing efficiency within the steering gearbox, ensuring optimal hydraulic pressure retention and smooth steering operation.
Built according to OEM specifications, the kit contains a full range of sealing and protection components required during major steering assembly servicing. Each component is precision-manufactured to prevent oil leakage, block dust and contaminants, and minimize wear on internal steering parts under heavy-duty operating conditions.
This major seal kit is ideal for complete steering gearbox rebuilding, preventive maintenance, and professional workshop repairs where reliability and long service life are critical.
Kit Contents (Complete Components Included):
Sealing & Protection Components
- Seal Protector – 1 No.
- Dirt Seal – 1 No.
- Double Lip Seal – 1 No.
- Trunion Seal – 1 No.
- Seal – Trunion Cover – 1 No.
- Seal – Side Cover – 1 No.
- Gasket HFB64 Side Cover – 1 No.
O-Rings
- O-Ring (Valve Housing) – 1 No.
- O-Ring (Valve) – 2 Nos.
- O-Ring (Worm Shaft) – 1 No.
- O-Ring (Rack Piston) – 1 No.
- O-Ring (Trunion Cover) – 1 No.
- O-Ring (Check Valve) – 1 No.
Seal Rings & Internal Seals
- Seal Ring – Rack Piston – 1 No.
- Seal Ring – Valve – 2 Nos.
- Seal Ring – Worm Shaft – 1 No.
- Seal Ring – Trunion – 1 No.
- Seal Ring – 1 No.
Washers & Backup Components
- Backup Washer – 1 No.
- Backup Washer (Side Cover) – 1 No.
Retaining & Fastening Components
- Retaining Ring – 1 No.
- Retaining Ring (Internal) – 1 No.
- Seal Nut 3/8″-24 UNF-3B – 2 Nos.
- Seal Nut 5/8″-18 UNF-3B – 1 No.
Additional Components
- Seat Ring (Valve) – 2 Nos.
- Plug – Side Cover Vent – 1 No.
Key Features
- Complete OEM steering overhaul kit
- Suitable for Ashok Leyland & Tata M&HCV applications
- Ensures leak-proof hydraulic performance
- Protects against dust, contamination, and wear
- Improves steering smoothness and reliability
- Ideal for full steering gearbox rebuilding
